Mold Heating
Temperature

Power(Optional)

RT-300°C/0.6KW
RT-500°C/1KW
RT-800°C/3.5 KW

RT-300°C/1.2KW
RT-500°C/2.4KW
RT-800°C/5 KW

RT-300°C/2.5KW
RT-500°C/4KW

RT-300°C/3KW
RT-500°C/5KW

Pressure Range

0-5T

0-10T

0-15T

0-15T

Piston Diameter

(Chrome-Plated Cylinder)

ф50 mm

Ф65 mm

Ф95 mm

Ф95 mm

Pressure Accuracy

0.01 ton

Overall Structure of the Main Body

The equipment adopts seal free connections to reduce oil leakage points

Constant Temperature Time

1S~∞S

Temperature Control Accuracy

0.1 ℃

Heat Insulation Methods

lmported Heat Insulation Board

Display Screen

5-inches Touch Screen

7-inches Touch Screen

Heating Method

Multi-stage Heating or Cooling Program

Heat Insulation Methods

lmported Heat insulation Panel

Cooling Methods

Water-cooled Rapid Cooling [Water Chiller Selection]

Working Space

120x55 mm

180 x60mm

200 x60mm

300 x 65mm

400 x 70mm

Power Supply Power

220V/110V Customizable

Plate Size
Double-Plate Heating
(M X N)

120 x 120mm

180 x 180mm

200x200mm

300x300mm

400x400mm

Product Dimensions/Weight

250x230x380mm/
55 kg

320x290x420 mm/95 kg

450x420x450mm
/180 kg

550x520x460mm
/380 kg

Package Dimensions/Gross Weight

405x330x550mm/
64 kg

405x330x550 mm/104 kg

725x620x890mm
/216 kg

725x620x890mm /416 kg

Actual output pressure

Pressure gauge system pressure

Pressure gauge type

1 T

1.41 MPa

2T

2.82 MPa

3 T

4.23 MPa

5 T

7.06 MPa

8 T

11.3 MPa

10 T

14.1 MPa

15 T

21.2 MPa

20 T

28.3 MPa

24 T

34.0 MPa

Pressure calculation formula

The area of the oil cylinder/the area of the mold × the reading of the pressure gauge = the actual pressure of the mold (Mpa)

Note

The system pressure (ie pressure gauge reading) should not exceed 34MPa, otherwise it will affect the service life of the equipment
